LLAVES
WRENCHES
08 CLÉS
SCHLÜSSEL
CHIAVI
CHAVES
КЛЮЧИ

INCH

COD. I L (mm) A (mm) B (mm) C (mm) D (mm) +fm
57148 1/4- 5/16
135 15 19 8,0 8,0 55
57149 5/16- 3/8
57150 7/16- 1/2 155 20 23 9,0 9,0 90 10 ● B
57151 9/16- 5/8 185 25 28 10 10 160
57152 11/16- 3/4 210 28 31 11 11 210
57153 13/16- 7/8 230 32 35 12 12 300
DIN 475
CARACTERÍSTICAS / FEATURES / CARACTÉRISTIQUES
Cr-V
PARA RACORES / FLARE NUT / POLYGONALE À TUYAUTER / OFFENER DOPPELRINGSCHLÜSSEL / CHIAVE PER RACCORDI / LUNETAS ABERTAS COM BATENTE / КЛЮЧ
ДЛЯ КОНИЧЕСКИХ ГАЕК
MM

COD. H L (mm) A (mm) B (mm) C (mm) D (mm) E (mm) F (mm) +fm

60785 8-10 145 19 6,0 7,5 21 7,5 45
60786 9-11 6,5 22 9,0
150 21 9,0 55
60787 10-11 7,5 23 8,5 10
60788 11-13 165 22 8,5 10 25 10
100
60789 12-14 180 25 9,5 11 28 9,0 11
● B
60790 17-19 210 31 14 15 34 12 13 165
60791 19-22 230 34 18 17 39 14 200
16 8
60792 22-24 250 39 17 18 41 15 290
60793 24-27 260 42 18 21 46 16 17 280
60794 30-32 280 48 22 24 50 20 23 460 6
DIN 3118
CARACTERÍSTICAS / FEATURES / CARACTÉRISTIQUES
Cr-V
SET
MM
°
COD. PCS. COD. (mm)
68587 6 90056 60785, 60788, 60789, 60790, 60792, 60793 8-10, 11-13, 12-14, 17-19, 22-24, 24-27
B 60785, 60786, 60787, 60788, 60789, 60790, 60791, 8-10, 9-11, 10-11, 11-13, 12-14, 17-19, 19-22, 22-24,
68588 10 90058
60792, 60793, 60794 24-27, 30-32

B Cromado aeroespacial / Aerospatial chrome plating / Chromée aérospatiale / Verchromt aerospatiale / Cromate satinate / Cromado fosco aerospacial / Матовый хром
